Nickel-Metal Hydride
For over four decades, Nickel Metal Hydride (NiMH) batteries have been the trusted power source for demanding applications. Renowned for their safety and reliability, they meet stringent industry standards.
Our product range offers a diverse selection of NiMH batteries in various sizes and specifications to meet different industrial requirements.
Optimized for high-drain devices requiring frequent battery replacements, such as telecommunications, IoT, and emergency lighting, GP NiMH batteries deliver exceptional performance and reliability.
NiMh Series
Performance Comparison
- Standard series
- High Drain Series
- Long Cycle Life Series
- Endurance and Longer Life Series
Standard series
Standard NiMH batteries offer a balanced combination of charge retention, power output, and lifespan. The advanced formulation of GP Batteries achieves one of the highest energy capacities available on the market.
All round performance
Excellent overall performance, suited for a wide range of industrial applications.
High capacity
Excellent capacity with a longer run time between charges.
Long cycle life
Long cycle life NimH batteries can withstand multiple charge and discharge cycles, offering excellent performance for your application.
Product range
Cell size | Model | Dimension (mm) | Nominal Voltage (V) | Rated Capacity (mAh) | Typical Capacity (mAh) | Approx Weight (g) | LSD Type | ||
---|---|---|---|---|---|---|---|---|---|
1/3AAA | GP17AAAH # | Ø 10.4 | H 14.1 | 1.2 | 170 | 180 | 4.2 | L80-1 | |
2/3AAA | GP30AAAM **# | Ø 10.4 | H 29.3 | 1.2 | 300 | 300 | 7.5 | L80-1 | |
AAA | GP42AAAHS **# | Ø 10.5 | H 44.2 | 1.2 | 440 | 460 | 10.5 | L80-1 | |
AAA | GP50AAAH **# | Ø 10.5 | H 43.7 | 1.2 | 500 | 520 | 10.5 | L80-1 | |
AAA | GP50AAAHC **# | Ø 10.5 | H 44.5 | 1.2 | 500 | 520 | 12.0 | L80-1 | |
AAA | GP55AAAH *## | Ø 10.5 | H 44.5 | 1.2 | 550 | 580 | 13.0 | L50-1 | |
AAA | GP50AAAH **# | Ø 10.5 | H 43.7 | 1.2 | 600 | 630 | 13.0 | L80-1 | |
AAA | GP55AAAH **# | Ø 10.5 | H 43.7 | 1.2 | 660 | 680 | 13.0 | L80-1 | |
AAA | GP65AAAHC **# | Ø 10.5 | H 44.5 | 1.2 | 660 | 680 | 13.0 | L80-1 | |
AAA | GP70AAAH **# | Ø 10.5 | H 43.7 | 1.2 | 700 | 730 | 13.0 | L80-1 | |
AAA | GP75AAAH **# | Ø 10.5 | H 43.7 | 1.2 | 750 | 780 | 13.0 | L80-1 | |
AAA | GP90AAAH ** | Ø 10.5 | H 43.7 | 1.2 | 800 | 830 | 13.0 | L80-1 | |
AAA | GP85AAAHC **# | Ø 10.5 | H 44.5 | 1.2 | 850 | 860 | 14.5 | L80-1 | |
AAA | GP95AAAH **# | Ø 10.5 | H 43.7 | 1.2 | 900 | 930 | 15.2 | L50-1 | |
AAA | GP91AAALH ** | Ø 10.5 | H 50.0 | 1.2 | 910 | 930 | 15.1 | L80-1 | |
2/3AA | GP60AAH # | Ø 14.5 | H 28.7 | 1.2 | 600 | 620 | 14.0 | L80-1 | |
2/3AA | GP75AAH | Ø 14.5 | H 28.7 | 1.2 | 750 | 770 | 15.0 | L80-1 | |
AA | GP50AAM ** | Ø 14.4 | H 48.2 | 1.2 | 600 | 820 | 15.5 | L80-1 | |
AA | GP70AAMD | Ø 14.4 | H 48.2 | 1.2 | 700 | 730 | 17.0 | L80-1 | |
AA | GP90AAMD # | Ø 14.4 | H 48.2 | 1.2 | 900 | 930 | 20.0 | L80-1 | |
AA | GP130AAM **# | Ø 14.4 | H 48.2 | 1.2 | 1300 | 1350 | 25.0 | L80-1 | |
AA | GP130AAHC **# | Ø 14.5 | H 50.5 | 1.2 | 1300 | 1550 | 25.0 | L80-1 | |
AA | GP150AAM **# | Ø 14.4 | H 48.2 | 1.2 | 1500 | 1550 | 26.0 | L80-1 | |
AA | GP160AAH **# | Ø 14.5 | H 49.2 | 1.2 | 1600 | 1650 | 26.0 | L80-1 | |
AA | GP150AAHC # | Ø 14.5 | H 50.5 | 1.2 | 1600 | 1650 | 26.0 | L80-1 | |
AA | GP180AAH **# | Ø 14.5 | H 49.2 | 1.2 | 1800 | 1850 | 28.0 | L80-1 | |
AA | GP180AAHC **# | Ø 14.5 | H 50.5 | 1.2 | 1800 | 1850 | 28.0 | L80-1 | |
AA | GP200AAH **# | Ø 14.5 | H 49.2 | 1.2 | 2000 | 2060 | 29.5 | L80-1 | |
AA | GP210AAHC **# | Ø 14.5 | H 50.2 | 1.2 | 2000 | 2060 | 28.0 | L80-1 | |
AA | GP220AAH **# | Ø 14.5 | H 49.2 | 1.2 | 2200 | 2250 | 29.5 | L80-1 | |
AA | GP230AAHC **# | Ø 14.5 | H 50.5 | 1.2 | 2200 | 2250 | 29.5 | L80-1 | |
4/5AF | GP211AFH ** | Ø 17.0 | H 43.0 | 1.2 | 2100 | 2150 | 33.0 | L50-1 | |
AF | GP270AFH ** | Ø 17.0 | H 50.0 | 1.2 | 2600 | 2700 | 39.5 | L50-1 | |
7/5AF | GP380AFH **# | Ø 17.0 | H 67.0 | 1.2 | 3800 | 3820 | 53.5 | L50-1 | |
18670 | GP380LAHV ** | Ø 18.3 | H 67.0 | 1.2 | 3800 | 3990 | 60.0 | L50-1 | |
18670 | GP450LAH ** | Ø 18.3 | H 67.0 | 1.2 | 4300 | 4500 | 63.0 | L50-1 | |
Button | GP40BVH ** | Ø 11.7 | H 5.5 | 1.2 | 40 | 40 | 2.0 | L30-1 | |
Button | GP80BVH ** | Ø 15.5 | H 6.4 | 1.2 | 80 | 80 | 4.0 | L30-1 | |
Button | GP250BVH | Ø 25.2 | H 6.4 | 1.2 | 250 | 250 | 12.0 | L30-1 | |
Button | GP320BVH | Ø 25.2 | H 8.7 | 1.2 | 320 | 320 | 14.1 | L30-1 | |
9V | GP17R8H ** | T 17.5 | W 25.5 | H 48.5 | 8.4 | 170 | 175 | 32.0 | L80-1 |
9V | GP17R9H ** | T 17.5 | W 25.5 | H 48.5 | 9.6 | 170 | 175 | 36.0 | L80-1 |
9V | GP20R7H | T 17.5 | W 25.5 | H 48.5 | 7.2 | 200 | 210 | 36.5 | L80-1 |
9V | GP20R8H # | T 17.5 | W 25.5 | H 48.5 | 8.4 | 200 | 210 | 42.5 | L80-1 |
Ambient temperature range: Standard charge:0 to 45°C, Discharge: -20 to 50°C, Storage -20 to 35°C.
#With IEC62133
**With UL2054 approval
High drain series
High drain Nickel Metal Hydride batteries are designed for applications requiring a substantial power supply. Their capacity to efficiently manage high discharge rates provides excellent performance and reliability.
High discharge rate
These batteries are designed to withstand high power demands while maintaining performance and longevity.
Power delivery
Suitable for industrial applications requiring high power.
Long cycle life
The battery cells have a long cycle life, capable of enduring numerous charge and discharge cycles.
Product range
Cell size | Model | Dimension (mm) | Nominal Voltage (V) | Rated Capacity (mAh) | Typical Capacity (mAh) | Approx Weight (g) | LSD Type | Max. Discharge Cureent (A) | |
---|---|---|---|---|---|---|---|---|---|
AA | GP130AAHV # | Ø 14.5 | H 49.2 | 1.2 | 1300 | 1350 | 26.0 | L50-1 | 13 |
AA | GP150AAHV # | Ø 14.5 | H 49.2 | 1.2 | 1500 | 1550 | 27.0 | L50-1 | 15 |
SC | GP130SCHSV **# | Ø 23.0 | H 43.0 | 1.2 | 1300 | 1350 | 31.0 | L50-1 | 13 |
SC | GP150SCHSV # | Ø 23.0 | H 43.0 | 1.2 | 1500 | 1580 | 36.5 | L50-1 | 15 |
SC | GP180SCHSV **# | Ø 23.0 | H 43.0 | 1.2 | 1800 | 1850 | 43.0 | L50-1 | 18 |
SC | GP220SCHSV **# | Ø 23.0 | H 43.0 | 1.2 | 2200 | 2300 | 43.8 | L50-1 | 22 |
SC | GP220SCH **# | Ø 23.0 | H 43.0 | 1.2 | 2200 | 2310 | 55.0 | L50-1 | 22 |
SC | GP260SCHV | Ø 23.0 | H 43.0 | 1.2 | 2600 | 2650 | 52.0 | L50-1 | 26 |
SC | GP300SCHSV **# | Ø 23.0 | H 43.0 | 1.2 | 3000 | 3100 | 56.0 | L50-1 | 30 |
SC | GP300SCH | Ø 23.0 | H 43.0 | 1.2 | 3000 | 3100 | 56.0 | L50-1 | 33 |
SC | GP330SCH | Ø 23.0 | H 43.0 | 1.2 | 3300 | 3430 | 62.0 | L50-1 | 33 |
C | GP350CH | Ø 25.8 | H 50.0 | 1.2 | 3500 | 3850 | 78.5 | L50-1 | 16.5 |
C | GP1000CH | Ø 25.8 | H 86.0 | 1.2 | 10000 | 10250 | 169.0 | L50-1 | 50 |
D | GP700DH **# | Ø 33.0 | H 60.0 | 1.2 | 7000 | 7000 | 155.0 | L50-1 | 35 |
D | GP900DH ** | Ø 33.0 | H 60.0 | 1.2 | 9000 | 9225 | 170.0 | L50-1 | 45 |
D | GP1100DH | Ø 33.0 | H 60.0 | 1.2 | 11000 | 11550 | 179.0 | L50-1 | 55 |
Ambient temperature range: Standard charge:0 to 45°C, Discharge: -20 to 50°C, Storage -20 to 35°C.
#With IEC62133
**With UL2054 approval
Long cycle life series
This Nickel Metal Hydrid series excels in charge retention, making it ideal for applications demanding frequent and deep cycles. With an impressive lifespan of up to 1000 cycles, these cells maintain over 85% of their original capacity after a full year, ensuring reliable performance over time.
High capacity
These battery cells have a high capacity, extending your device’s runtime between charges.
High charge retation
These battery cells have minimal self-discharge, meaning they retain their charge exceptionally well over time. After a year, they still hold over 85% of their original capacity.
Long cycle life
Designed to withstand numerous charge and discharge cycles without significant degradation in performance.
Product range
Cell size | Model | Dimension (mm) | Nominal Voltage (V) | Rated Capacity (mAh) | Typical Capacity (mAh) | Approx Weight (g) | LSD Type | Cycle Life | |
---|---|---|---|---|---|---|---|---|---|
AAA | GP85AAAHCB **# | Ø 10.5 | H 44.5 | 1.2 | 800 | 820 | 14.0 | L80-1 | 1000 |
aa | GP210AAHCB **# | Ø 14.5 | H 50.5 | 1.2 | 2000 | 2050 | 30.0 | L80-1 | 1000 |
Ambient temperature range: Standard charge:0 to 45°C, Fast charge: 10 to 45°C, Discharge: -20 to 50°C, Storage -20 to 35°C.
#With IEC62133
**With UL2054 approval
Endurance and longer life series
This Nickel Metal Hydride series offers an impressive lifespan of up to 10 years, making it ideal for applications in extreme temperature conditions, ranging from -35°C to 85°C. Built with durability and robustness in mind, these cells maintain safety and performance even in the harshest environments.
Long cycle life
With more than 500 cycles these batteries offer a reliable and cost-effective power solution.
Operating temperature
The battery cells have a high endurance and can operate in temperatures between -35°C – +80°C
Long service life
With a service life of up to 10 years, these cells are ideal for backup applications that require long-term reliability.
Product range
Cell size | Model | Dimension (mm) | Nominal Voltage (V) | Rated Capacity (mAh) | Typical Capacity (mAh) | Approx Weight (g) | LSD Type | IEC Designation | |
---|---|---|---|---|---|---|---|---|---|
AAA | GP60AAAHT # | Ø 10.5 | H 43.7 | 1.2 | 600 | 630 | 14.0 | L80-1 | T |
AAA | GP60AAAHT3 **# | Ø 10.5 | H 43.7 | 1.2 | 600 | 630 | 14.0 | L70-1 | NA |
AAA | GP60AAAHT4 | Ø 10.5 | H 43.7 | 1.2 | 600 | 630 | 14.0 | L70-1 | NA |
AA | GP110AALHT # | Ø 14.5 | H 50.5 | 1.2 | 1100 | 1155 | 23.5 | L80-1 | U |
AA | GP125AAMT **# | Ø 14.5 | H 48.2 | 1.2 | 1250 | 1280 | 24.0 | L80-1 | T |
4/5AF | GP160AFHT # | Ø 17.0 | H 43.0 | 1.2 | 1600 | 1680 | 33.0 | L80-1 | T |
AF | GP210AFHT # | Ø 17.0 | H 50.0 | 1.2 | 2100 | 2200 | 38.0 | L80-1 | T |
7/5AF | GP370AFLHT | Ø 17.5 | H 69.0 | 1.2 | 3700 | 3800 | 60.0 | L80-1 | T |
18700 | GP400LAHT # | Ø 18.3 | H 70.0 | 1.2 | 4000 | 4120 | 67.0 | L80-1 | T |
18900 | GP400LAHT #** | Ø 18.3 | H 90.0 | 1.2 | 4000 | 4120 | 76.0 | L80-1 | U |
SC | GP220SCHT **# | Ø 23.0 | H 43.0 | 1.2 | 2200 | 2310 | 53.0 | L80-1 | U |
SC | GP220SCHTD # | Ø 23.0 | H 43.0 | 1.2 | 2200 | 2310 | 53.5 | L80-1 | U |
C | GP300CHT | Ø 25.0 | H 50.0 | 1.2 | 3000 | 3100 | 75.0 | L80-1 | T |
D | GP700DHT ** | Ø 33.0 | H 60.5 | 1.2 | 7000 | 7350 | 146.0 | L80-1 | U |
Ambient temperature range: Standard charge:0 to 70°C, Discharge: -20 to 70°C, Storage -20 to 35°C.
#With IEC62133
**With UL2054 approval
